INDEX

Load star model	Features	Download
ZA1 = load cell NL-20K+Indicator ND 710	Max measurement force 200N(20kgf)
ZB1=load cell NL-200K+Indicator ND710	Max measurement force 2kN(200kgf)
ZC1=loadcellNLNL500K+Indicator ND710	Max measurement force 5kN(500kgf)
ZG1=loadcellNLNL500K+Indicator ND710	Max measurement force 5kN(500kgf) Only for toggle press
O/No.14	BCD output
O/No.74	RS232C interface
O/No.76	RS422/485 interface
NDD-01	curve software
RSAQ5	USB RS232C communication cable
Options for Hand press	Features	Download
R/Y（Return stroke lock）	the return stroke lock guarantees reaching the required pressing depth with every stroke.
S（Throat extension block and Mounting plate)	To extend throat depth and corresponding table.  Extension 60 mm for NH202 and RT501.

Options

Load Star ; Integrate Load Cell and Piece Counter
Acknowledgement of OK/NOK is integrated in LOAD CELL.

• Large and High visibility LED display.
• Connectable with PLC, PC by installing circuit board.
• Process data can be visualized as curve on PC close at hand by installed analysis software.
• Function of force monitoring and OK/NOK decision is available.
  High productivity and quality control is realized without sampling.
• Auto process counter is integrated.
• 3 process modes (Peak mood, Section peak mood, Track mood)
  are available.
  The required process mode can be selected.
• NAKASEIKI LOAD CELL NL-20K NL-200K NL-500K
• load cell NL-20K+Indicator ND 710 load cell NL-200K+Indicator ND710 loadcellNLNL500K+Indicator ND710
