force gauge - DN-FGA

High resolution, simple measurement of tension/compression force, switch test, connector insertion/withdraw test, fracture test and push pull testing equipment

· Indication of Measuring Unit: Kgf, N, lbf, ozf

· A/D Transducer: 16-bit, 100 times/sec

· D/A Transducer: 12-bit

· Indication of Measuring Value: 5 Digit LCD (indicating forward/reverse direction)

· Condition indicating LED: Indication of charge and compare output condition

· Compare Output: High, Low, Good

· Analog Output: DC +/-1V

· Communication Output: USB

· Range of using temperature: -10℃ to 40℃, 80% RH and below (in locations without due condensation phenomenon)

· Weight: Approximately 600g

· Electric Source: Nickel hydrogen (NimH), Chargeable Adapter (DC 9V)

· Continuous Use Life: Approximately 40 hours

· Charging Time: Approximately 8 hours

· Option OP-01: USB cable, OP-02 :Analog out and open collector connector.

Specifications

Model	FGA-K2	FGA-K5	FGA-K20	FGA-K50	FGA-K100	FGA-K500	FGA-T1
Capacity	2.000kg	5.000kg	20.00kg	50.00kg	100.00kg	500.0kg	1000.0kg
Min load	0.001kg	0.001kg	0.01kg	0.01kg	0.05kg	0.1kg	0.5kg
Sensor conformation	Sensor Inside				Sensor Inside
Value error	±0.2%

force gauge - DLR

DLR is a tester stand especially designed to match DN-FGA series and can be combined into a wide use of stand, which usually applied in various testing purpose, such as switch test, connector insertion/withdraw test, and fracture tester. The motive carrier are designed with the test stand and can be moved on
X & Y axis. The design is convenient to fix clamps.
L : 250*W:360*H:470
Capacity : 500N
Stroke : 180mm
Net weight : 18kg
- Vertical and Horizontal model, high stability .
- Manual operation, trapezoid stroke power transfer, Easy and stable to operate.
- May install the stand on table for using, this installation is more steady.
