Product Information :

Name :
Pneumatic Gripper for Robot
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. OMIL
Brand :
OMIL
Model :
Pneumatic Gripper 2 finger parallel 3 finger self-centering 4 finger self-centering angular gripper
Product Type :
  1. สินค้า, ผลิตภัณฑ์
Short Description :
OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMIL OMILPneumatic Gripper 2 finger parallel 3 finger self-centering 4 finger self-centering angular gripper

Product Detail :









Safety device to preserve the gripping force

M5 pressurisation

Version up to 130°C

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
MAC3-50 270 9 0.22 50 / 0.15 2D 3D
MAC3-64 580 - 970 12 - 6 0.4 64 / 0.32 2D 3D
MAC3-80 1000 - 2300 16 - 8 0.75 80 / 0.55 2D 3D
MAC3-100 1800 - 4050 20 - 10 1.4 100 / 1.05 2D 3D
MAC3-125 3000 - 5800 26 - 13 2.4 125 / 2 2D 3D
MAC3-160 6000-11000 32 - 16 4.9 160 / 3.3 2D 3D
MAC3-200 7100-16000 50 - 25 11.5 200 / 6.4 2D 3D
MAC3-250 18600... 60 - 30 21.5 250 / 8.7 2D 3D






Principle of operating: wedge-hook kinematics

Small gripper

Version up to 130°C

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
GPS 3-30 75 4 0.06 30 / 0.03 2D 3D
GPS 3-36 120 4 0.10 38 / 0.05 2D 3D
GPS 3-42 185 6 0.14 45 / 0.08 2D 3D






Through central hole from 8.2 to 60.5 mm

Safety device to preserve the gripping force

Spring packaged pressure plate

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
MFB 70 420 8 0.35 50 / 0.16 2D 3D
MFB 85 1000 12 0.7 64 / 0.32 2D 3D
MFB 110 1380 16 1.5 80 / 0.55 2D 3D
MFB 140 2180 20 3.5 100 / 1.05 2D 3D
MFB 170 3400 26 6 125 / 2 2D 3D
MFB 220 5500 32 9.5 160 / 3.3 2D 3D






Safety device to preserve the gripping force

Rating IP 67

Version up to 130°C

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
SRP 64 580 12 0.8 64 / 0.3   3D
SRP 80 1000 16 1.2 80 / 0.5
SRP 100 1800 20 2.1 100 / 0.95   3D
SRP 125 3000 26 3.85 125 / 1.75
SRP 160 6000 32 7.3 160 / 3
SRP 200 7100 50 18 200 / 5.5
SRP 250 10300 60 33 250 / 6.9







Operating principle: piston and synchronised opening/closing by toothed wheel

Big stroke

Spring packaged pressure plate

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
MCL 40 1650 - 2790 64 5.5 ... 100 / 1.7 ... 2D 3D
MCL 50 2440 - 4100 110 12 ... 135 / 3.9 ... 2D 3D
MCL 63 3060 / 5160 200 28 ... 300 / 7 ... 2D 3D
MCL 80 2600 320 75 300 / 8 2D 3D










Safety device to preserve the gripping force

Rating IP 67

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
GSO 40 110 5 0.12 40...   3D
GSO 50 125 - 260 8 - 4 0.25 50...   3D
GSO 64 225 - 470 12 - 6 0.39 64...   3D
GSO 80 375 - 775 16 - 8 0.68 80...   3D
GSO 100 625 - 1300 20 - 10 1.1 100...   3D
GSO 125 1025 - 2130 26 - 13 1.9 125...   3D
GSO 160 1560 - 3040 32 - 16 3.65 160...   3D








Safety to preserve gripping force

M5 pressurisation

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
            3D
OPP - 40 110 5 0.08 50 / 0.10 2D 3D
OPP - 50 125 - 260 8 - 4 0.15 64.../0.18 2D 3D
OPP - 64 220 - 450 12 - 6 0.28 80.../0.35 2D 3D
OPP - 80 360 - 720 16 - 8 0.5 100.../0.6 2D 3D
OPP - 100 560 - 1160 20 - 10 0.81 125.../1.1 2D 3D
OPP - 125 910 - 1860 26 - 13 1.35 160.../2.1 2D 3D
OPP - 160 1490 - 2750 32 - 16 2.6 200.../3.5 2D 3D








Safety to preserve gripping force

M5 pressurisation

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
OPP2-64 220 - 420 12 - 6 0.27 64 / 0.32 2D 3D
OPP2-80 360 - 540 16 - 8 0.45 80 / 0.55 2D 3D
OPP2-100 550 - 900 20 - 10 0.8 100 / 1.05 2D 3D
OPP2-125 845 - 1520 26 - 13 1.4 125 / 2 2D 3D
OPP2-160 1490 - 2680 32 - 16 2.6 160 / 3.3 2D 3D
OPP2-180 1560 - 2800 40 - 20 4.4 180 / 4.3 2D 3D
OPP2-200 2200 - 3950 50 - 25 6.2 200 / 6.4 2D 3D
OPP2-250 3650 - 6150 60 - 30 12.4 250 / 8.7 2D 3D
OPP2-320 4860 - 8410 72 - 36 19 320 / 11.8 2D 3D








Operating principle: wedge-hook kinematics

Safety device to preserve the gripping force

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
PEP 10 30 - 16 4 - 7 0.055 25 / 0.015 2D 3D
PEP 16 94 - 54 6 - 11 0.13 32 / 0.04 2D 3D
PEP 20 150 - 86 10 - 17 0.23 42 / 0.08 2D 3D
PEP 25 200 - 140 14 - 21 0.45 52 / 0.18 2D 3D
PEP 32 290 22 0.75 60 / 0.38 2D 3D
PEP 40 445 30 1.28 75 / 0.68 2D 3D
PEP 56 950 47 2.6 100 / 1.42 2D 3D
PEP 70 1440 63 5.2 125 / 2.35 2D 3D






Safety device to preserve the gripping force

M5 Pressurisation

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
OPM 030 60 80 0.08 35 / 0.1 2D 3D
OPM 040 100 11 0.11 40 / 0.1 2D 3D
OPM 050 190 14 0.2 50 / 0.16 2D 3D
OPM 064 410 - 340 12 - 18 0.38 64 / 0.32 2D 3D
OPM 080 650 - 540 16 - 24 0.68 80 / 0.55 2D 3D
OPM 100 1100 - 920 20 - 30 1.2 100 / 1.05 2D 3D
OPM 125 2000 - 1670 26 - 35 2.2 125 / 2 2D 3D
OPM 160 3700 - 3100 32 - 42 4.3 160 / 3.3 2D 3D






Operating principle: fingers sliding, guided by rack and pinion for concentric gripping

Big stroke

Sliding: precise slide rail

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
GHL 12 95 12 - 48 0.15 ....... 45 / 0.08 2D 3D
GHL 16 170 16 - 64 0.35 ...... 65 / 0.16 2D 3D
GHL 20 270 20 - 80 0.65 ...... 82 / 0.3 2D 3D








Safety device to preserve the gripping force

Rating IP 67

Version up to 130°C

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
SRO 80 330 16 0.8 80 / 0.5 2D 3D
SRO 100 510 20 1.3 100 / 0.95 2D 3D
SRO 125 760 26 2.3 125 / 1.75 2D 3D
SRO 160 1200 32 4 160 / 3 2D
SRO 180 1380 40 5.8 180 / 3.7 2D
SRO 200 1780 50 8.3 200 / 5.5 2D
SRO 250 3200 60 16.5 250 / 6.9 2D






Operating principle: fingers sliding, guided by rack and pinion for concentric gripping

Big stroke

Rating IP 54



 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
PLE 16 170 30 - 60 0.59 ...... 90 / 0.3 2D 3D
PLE 20 270 40 - 80 1.03 ...... 120 / 0.55 2D 3D
PLE 25 420 50 - 100 1.7 ...... 145 / 0.9 2D 3D
PLE 32 700 70 - 120 2.9 ...... 170 / 1.5 2D 3D
PLE 40 1100 100 - 160 5.3 ...... 230 / 2.45 2D 3D






Operating principle: fingers sliding, guided by rack and pinion for concentric gripping

Big stroke

Rating IP 40 / IP 54 on request

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
PLG 25 460 80 - 120 1.7 ... 160/2   3D
PLG 40 1050 120 - 200 3.6 ... 210/2.8   3D
PLG 60 2400 120 - 400 5.6 ... 270/ 3.9   3D








Operating principle: fingers sliding, guided by rack and pinion for concentric gripping

Big stroke

Rating IP 40 / IP 54 on request

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
GPL 16 170 40 - 160 0.6 ...... 130 / 1 2D 3D
GPL 25 460 80 - 160 1.7 ...... 160 / 2 2D 3D
GPL 40 1050 80 - 300 3 ...... 210 / 2.8 2D 3D
GPL 60 2400 120 - 400 5.6 ...... 270 / 3.9 2D 3D








Operating principle: fingers sliding, guided by rack and pinion for concentric gripping

Big stroke

Slidind: precise slide rail

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
GPRS 60 2300 300 17 ...... 600 / 7.5 2D 3D
GPRS 80 5100 300 31 ...... 900 / 12 2D 3D






 -Gripping force 10.000 N

- Repeatability 0.1 mm

- Solution to control all the stroke

 Download pdf

Part numberGripping force_(N)Total stroke (mm)Mass (kg)Max finger length/ WeightCAD
PSG 100 10.000 200 36 500 / 15   3D










Safety device to preserve the gripping force

M5 Pressurisation

Version up to 130°C

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
MA 4-75 770 - 1290 12 - 6 0.8 64 / 0.3 2D 3D
MA 4-95 1330 - 3060 16 - 8 1.5 80 / 0.5 2D 3D
MA 4-110 2400 - 5330 20 - 10 2 100 / 0.95 2D 3D
MA 4-145 4130 - 7700 26 - 13 4.4 125 / 1.75 2D 3D
MA 4-185 8000-14670 32 - 16 8.5 160 / 3 2D 3D
MA 4-230 25380... 50 - 25 16.8 200 / 5.5 2D 3D






Principle of operating: wedge-hook kinematics

Small gripper

Version up to 130°C

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
GPS 4-30 95 4 0.07 30 / 0.02 2D 3D
GPS 4-36 145 4 0.11 38 / 0.04 2D 3D
GPS 4-42 230 6 0.16 45 / 0.07 2D 3D






Through central hole from 15.5 to 30.5 mm

Principe of operating: wedge-hook kinematics

Spring packaged pressure plate

 Download pdf

Part numberGripping force (N)Total stroke (mm)Mass (kg)Max finger length/WeightCAD
MFB/4-85 1200 12 0.75 64 / 0.3 2D 3D
MFB/4-110 1700 16 1.6 80 / 0.5 2D 3D
MFB/4-140 2900 20 3.7 100 / 0.95 2D 3D








Opening 10° for jaw PLA 10, 15° for jaw PLA 10

Operating principle: piston and lever

Small gripper

 Download pdf

Part numberGripping torque (Ncm)Total strokeMass (kg)Max finger length/WeightCAD
PLA 10 14 0°-20° 0.035 38 / 0.03 2D 3D
PLA 16 55 0°-30° 0.11 55 / 0.05 2D 3D






Opening 20° for jaw

Operating principle: piston and lever

Safety device to preserve the gripping force

 Download pdf

Part numberGripping torque (Ncm)Total strokeMass (kg)Max finger length/WeightCAD
OPLE 030 75 0°-40° 0.08 38 / 0.04 2D 3D
OPLE 040 150 0°-40° 0.11 45 / 0.08 2D 3D
OPLE 050 400 0°-40° 0.2 50 / 0.12 2D 3D
OPLE 064 900 0°-40° 0.38 68 / 0.3 2D 3D
OPLE 080 1820 0°-40° 0.68 80 / 0.45 2D 3D
OPLE 100 3900 0°-40° 1.2 95 / 0.75 2D 3D









Opening 90° for jaw

Operating principle: piston and mechanical articulation for concentric closing

Version up to 130°C

 Download pdf

Part numberGripping torque (Ncm)Total strokeMass (kg)Max finger length/WeightCAD
PGC 14 120 0°-180° 0.10 42 / 0.05   3D
PGC 16 220 0°-180° 0.18 50/ 0.07 2D 3D
PGC 20 420 0°-180° 0.26 58 / 0.1 2D 3D
PGC 25 700 0°-180° 0.4 67 / 0.13 2D 3D
PGC 32 1400 0°-180° 0.6 80 / 0.25 2D 3D
PGC 40 2800 0°-180° 1.1 100 / 0.35 2D 3D
PGC 50 5400 0°-180° 1.9 125 / 0.7 2D 3D
PGC 63 11000 0°-180° 2.8 145 / 1.2 2D 3D
