Product Information :

Name :
Angle Head
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. HOLD WELL
Brand :
HOLD WEL Angle Head
Model :
HOLD WEL Angle Head
Short Description :
HOLD WEL Angle Head Universal Angle Head Modular Angle Head Heavy Duty Angle Head Aluminum Angle Head Slim Angle Head Angle Head Accessories

Product Detail :

Modular Angle Head



Universal Angle Head





Heavy Duty Angle Head



Aluminum Angle Head



Slim Angle Head



ngle Head Accessories
Collet

Collet

more
Extension

Extension

more
Flanged Setting Plate

Flanged Setting Plate

more
Setting Block / Stopper

Setting Block / Stopper






- AHD ( A1/A3 Type )
AHD-BT40-A1 90 degree Angle Head

AHD-BT40-A1 90 degree Angle Head

more
AHD-BT40-A3 90 degree Angle Head

AHD-BT40-A3 90 degree Angle Head

more
AHD-BT50-A1 90 degree Angle Head

AHD-BT50-A1 90 degree Angle Head

more
AHD-BT50-A3 90 degree Angle Head

AHD-BT50-A3 90 degree Angle Head

more
AHD-CAT40-A1 90 degree Angle Head

AHD-CAT40-A1 90 degree Angle Head

more
AHD-CAT40-A3 90 degree Angle Head

AHD-CAT40-A3 90 degree Angle Head

more
AHD-CAT50-A1 90 degree Angle Head

AHD-CAT50-A1 90 degree Angle Head

more
AHD-CAT50-A3 90 degree Angle Head

AHD-CAT50-A3 90 degree Angle Head

more
AHD-SK40-A1 90 degree Angle Head

AHD-SK40-A1 90 degree Angle Head

more
AHD-SK40-A3 90 degree Angle Head

AHD-SK40-A3 90 degree Angle Head

more
AHD-SK50-A1 90 degree Angle Head

AHD-SK50-A1 90 degree Angle Head

more
AHD-SK50-A3 90 degree Angle Head

AHD-SK50-A3 90 degree Angle Head

more

- AHD ( A1/A3 Type )

AHD-BT40-A1 90 degree Angle Head

AHD-BT40-A1 90 degree Angle Head
BT40-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

AHD ( A1/A3 Type )

AHD-BT40-A3 90 degree Angle Head

AHD-BT40-A3 90 degree Angle Head
BT40-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A1/A3 Type )

AHD-BT50-A1 90 degree Angle Head

AHD-BT50-A1 90 degree Angle Head
BT50-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

AHD ( A1/A3 Type )

AHD-BT50-A3 90 degree Angle Head

AHD-BT50-A3 90 degree Angle Head
BT50-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-CAT40-A1 90 degree Angle Head

AHD-CAT40-A1 90 degree Angle Head
CAT40-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-CAT40-A3 90 degree Angle Head

AHD-CAT40-A3 90 degree Angle Head
CAT40-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A1/A3 Type )

AHD-CAT50-A1 90 degree Angle Head

AHD-CAT50-A1 90 degree Angle Head
CAT50-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-CAT50-A3 90 degree Angle Head

AHD-CAT50-A3 90 degree Angle Head
CAT50-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-SK40-A1 90 degree Angle Head

AHD-SK40-A1 90 degree Angle Head
SK40-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A1/A3 Type )

AHD-SK40-A3 90 degree Angle Head

AHD-SK40-A3 90 degree Angle Head
SK40-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-SK50-A1 90 degree Angle Head

AHD-SK50-A1 90 degree Angle Head
SK50-ER20 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A1/A3 Type )

AHD-SK50-A3 90 degree Angle Head

AHD-SK50-A3 90 degree Angle Head
SK50-ER25 90° Angle Head (AHD Type_Longer)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation



 AHD ( A2/A4 Type )
AHD-BT40-A2 90 degree Angle Head

AHD-BT40-A2 90 degree Angle Head

more
AHD-BT40-A4 90 degree Angle Head

AHD-BT40-A4 90 degree Angle Head

more
AHD-BT50-A2 90 degree Angle Head

AHD-BT50-A2 90 degree Angle Head

more
AHD-BT50-A4 90 degree Angle Head

AHD-BT50-A4 90 degree Angle Head

more
AHD-CAT40-A2 90 degree Angle Head

AHD-CAT40-A2 90 degree Angle Head

more
AHD-CAT40-A4 90 degree Angle Head

AHD-CAT40-A4 90 degree Angle Head

more
AHD-CAT50-A2 90 degree Angle Head

AHD-CAT50-A2 90 degree Angle Head

more
AHD-CAT50-A4 90 degree Angle Head

AHD-CAT50-A4 90 degree Angle Head

more
AHD-SK40-A2 90 degree Angle Head

AHD-SK40-A2 90 degree Angle Head

more
AHD-SK40-A4 90 degree Angle Head

AHD-SK40-A4 90 degree Angle Head

more
AHD-SK50-A2 90 degree Angle Head

AHD-SK50-A2 90 degree Angle Head

more
AHD-SK50-A4 90 degree Angle Head

AHD-SK50-A4 90 degree Angle Head

more

- AHD ( A2/A4 Type )

AHD-BT40-A2 90 degree Angle Head

AHD-BT40-A2 90 degree Angle Head
BT40-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A2/A4 Type )

AHD-BT40-A4 90 degree Angle Head

AHD-BT40-A4 90 degree Angle Head
BT40-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-BT50-A2 90 degree Angle Head

AHD-BT50-A2 90 degree Angle Head
BT50-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-BT50-A4 90 degree Angle Head

AHD-BT50-A4 90 degree Angle Head
BT50-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-CAT40-A2 90 degree Angle Head

AHD-CAT40-A2 90 degree Angle Head
CAT40-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-CAT40-A4 90 degree Angle Head

AHD-CAT40-A4 90 degree Angle Head
CAT40-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation
.
- AHD ( A2/A4 Type )

AHD-CAT50-A2 90 degree Angle Head

AHD-CAT50-A2 90 degree Angle Head
CAT50-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A2/A4 Type )

AHD-CAT50-A4 90 degree Angle Head

AHD-CAT50-A4 90 degree Angle Head
CAT50-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-SK40-A2 90 degree Angle Head

AHD-SK40-A2 90 degree Angle Head
SK40-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-SK40-A4 90 degree Angle Head

AHD-SK40-A4 90 degree Angle Head
SK40-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

 AHD ( A2/A4 Type )

AHD-SK50-A2 90 degree Angle Head

AHD-SK50-A2 90 degree Angle Head
SK50-ER20 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( A2/A4 Type )

AHD-SK50-A4 90 degree Angle Head

AHD-SK50-A4 90 degree Angle Head
SK50-ER25 90° Angle Head (AHD Type_Compact)
Run-out ： 0.002 mm
Material ： Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 15 Nm
Gear Ratio ： 1：1
Spindle Type ： BT, SK(ISO), CAT
Standard Accessory： Hook Spanner ER Wrench, ER Nut
Output Rotation ： Reverse to Input Rotation

- AHD ( B1 Type )

AHD-CAT40-B1 45 degree Angle Head

AHD-CAT40-B1 45 degree Angle Head
CAT40-ER20 45° Angle Head (AHD Type)
Run-out：0.002 mm
Material：Ductile Cast Iron(FCD65)
R.P.M.：Max. 4000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type：BT, SK(ISO), CAT
Standard Accessory：Hook Spanner, End Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHD ( B1 Type )

AHD-BT40-B1 45 degree Angle Head

AHD-BT40-B1 45 degree Angle Head
BT40-ER20 45° Angle Head (AHD Type)
Run-out：0.002 mm
Material：Ductile Cast Iron(FCD65)
R.P.M.：Max. 4000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type：BT, SK(ISO), CAT
Standard Accessory：Hook Spanner, End Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHD ( B1 Type )

AHD-BT50-B1 45 degree Angle Head

AHD-BT50-B1 45 degree Angle Head
BT50-ER20 45° Angle Head (AHD Type)
Run-out：0.002 mm
Material：Ductile Cast Iron(FCD65)
R.P.M.：Max. 4000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type：BT, SK(ISO), CAT
Standard Accessory：Hook Spanner, End Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHD ( C1 Type )
AHD-BT40-C1 Modular Angle Head - Slim

AHD-BT40-C1 Modular Angle Head - Slim

more
AHD-BT50-C1 Modular Angle Head - Slim

AHD-BT50-C1 Modular Angle Head - Slim

more
AHD-CAT40-C1 Modular Angle Head - Slim

AHD-CAT40-C1 Modular Angle Head - Slim

more
AHD-CAT50-C1 Modular Angle Head - Slim

AHD-CAT50-C1 Modular Angle Head - Slim

more
AHD-SK40-C1 Modular Angle Head - Slim

AHD-SK40-C1 Modular Angle Head - Slim

more
AHD-SK50-C1 Modular Angle Head - Slim

AHD-SK50-C1 Modular Angle Head - Slim

more

- AHD ( C1 Type )

AHD-BT40-C1 Modular Angle Head - Slim

AHD-BT40-C1 Modular Angle Head - Slim
BT40-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation

- AHD ( C1 Type )

AHD-BT50-C1 Modular Angle Head - Slim

AHD-BT50-C1 Modular Angle Head - Slim
BT50-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation

 AHD ( C1 Type )

AHD-CAT40-C1 Modular Angle Head - Slim

AHD-CAT40-C1 Modular Angle Head - Slim
CAT40-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation

- AHD ( C1 Type )

AHD-CAT50-C1 Modular Angle Head - Slim

AHD-CAT50-C1 Modular Angle Head - Slim
CAT50-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation

- AHD ( C1 Type )

AHD-SK40-C1 Modular Angle Head - Slim

AHD-SK40-C1 Modular Angle Head - Slim
SK40-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation

- AHD ( C1 Type )

AHD-SK50-C1 Modular Angle Head - Slim

AHD-SK50-C1 Modular Angle Head - Slim
SK50-DC6 90° Angle Head (AHD_C1 Type)
Run-out ： 0.002 mm
Material Alloy Steel & Ductile Cast Iron
R.P.M. ： Max. 4000 RPM
Torque ： Max. 8 Nm
Gear Ratio ： 1：1
Spindle Type ：BT, SK(ISO), CAT
Standard Accessory ： Open End Wrench,L Type Wrench
Output Rotation ： Same as Input Rotation



- AHG ( A1/A2 Type )
AHG-BT40-A1 Universal Angle Head

AHG-BT40-A1 Universal Angle Head

more
AHG-BT40-A2 Universal Angle Head

AHG-BT40-A2 Universal Angle Head

more
AHG-BT50-A1 Universal Angle Head

AHG-BT50-A1 Universal Angle Head

more
AHG-BT50-A2 Universal Angle Head

AHG-BT50-A2 Universal Angle Head

more
AHG-CAT40-A1 Universal Angle Head

AHG-CAT40-A1 Universal Angle Head

more
AHG-CAT40-A2 Universal Angle Head

AHG-CAT40-A2 Universal Angle Head

more
AHG-CAT50-A1 Universal Angle Head

AHG-CAT50-A1 Universal Angle Head

more
AHG-CAT50-A2 Universal Angle Head

AHG-CAT50-A2 Universal Angle Head

more
AHG-SK40-A1 Universal Angle Head

AHG-SK40-A1 Universal Angle Head

more
AHG-SK40-A2 Universal Angle Head

AHG-SK40-A2 Universal Angle Head

more
AHG-SK50-A1 Universal Angle Head

AHG-SK50-A1 Universal Angle Head

more
AHG-SK50-A2 Universal Angle Head

AHG-SK50-A2 Universal Angle Head



- AHM ( BT-ER Type )
AHM-BT30-A04.180G 90 degree Aluminum Angle Head

AHM-BT30-A04.180G 90 degree Aluminum Angle Head

more
AHM-BT30-A04.180G-I 90 degree Aluminum Angle Head

AHM-BT30-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-BT30-A10.180G 90 degree Aluminum Angle Head

AHM-BT30-A10.180G 90 degree Aluminum Angle Head

more
AHM-BT40-A04.180G 90 degree Aluminum Angle Head

AHM-BT40-A04.180G 90 degree Aluminum Angle Head

more
AHM-BT40-A04.180G-I 90 degree Aluminum Angle Head

AHM-BT40-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-BT40-A10.180G 90 degree Aluminum Angle Head

AHM-BT40-A10.180G 90 degree Aluminum Angle Head

more
AHM-CAT30-A04.180G 90 degree Aluminum Angle Head

AHM-CAT30-A04.180G 90 degree Aluminum Angle Head

more
AHM-CAT30-A04.180G-I 90 degree Aluminum Angle Head

AHM-CAT30-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-CAT30-A10.180G 90 degree Aluminum Angle Head

AHM-CAT30-A10.180G 90 degree Aluminum Angle Head

more
AHM-CAT40-A04.180G 90 degree Aluminum Angle Head

AHM-CAT40-A04.180G 90 degree Aluminum Angle Head

more
AHM-CAT40-A04.180G-I 90 degree Aluminum Angle Head

AHM-CAT40-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-CAT40-A10.180G 90 degree Aluminum Angle Head

AHM-CAT40-A10.180G 90 degree Aluminum Angle Head

more
AHM-SK30-A04.180G 90 degree Aluminum Angle Head

AHM-SK30-A04.180G 90 degree Aluminum Angle Head

more
AHM-SK30-A04.180G-I 90 degree Aluminum Angle Head

AHM-SK30-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-SK30-A10.180G 90 degree Aluminum Angle Head

AHM-SK30-A10.180G 90 degree Aluminum Angle Head

more
AHM-SK40-A04.180G 90 degree Aluminum Angle Head

AHM-SK40-A04.180G 90 degree Aluminum Angle Head

more
AHM-SK40-A04.180G-I 90 degree Aluminum Angle Head

AHM-SK40-A04.180G-I 90 degree Aluminum Angle Head

more
AHM-SK40-A10.180G 90 degree Aluminum Angle Head

AHM-SK40-A10.180G 90 degree Aluminum Angle Head

more


 AHM ( BT-ER Type )

AHM-BT30-A04.180G 90 degree Aluminum Angle Head

AHM-BT30-A04.180G 90 degree Aluminum Angle Head
BT30-ER25 90° Aluminum Angle Head
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-BT30-A04.180G-I 90 degree Aluminum Angle Head

AHM-BT30-A04.180G-I 90 degree Aluminum Angle Head
BT30-ER25 90° Aluminum Angle Head (Internal Coolant)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-BT30-A10.180G 90 degree Aluminum Angle Head

AHM-BT30-A10.180G 90 degree Aluminum Angle Head
BT30-ER20 90° Aluminum Angle Head (Female Thread Nut)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-BT40-A04.180G 90 degree Aluminum Angle Head

AHM-BT40-A04.180G 90 degree Aluminum Angle Head
BT40-ER25 90° Aluminum Angle Head
(Internal Coolant)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-BT40-A04.180G-I 90 degree Aluminum Angle Head

AHM-BT40-A04.180G-I 90 degree Aluminum Angle Head
BT40-ER25 90° Aluminum Angle Head (Internal Coolant)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation
- AHM ( BT-ER Type )

AHM-BT40-A10.180G 90 degree Aluminum Angle Head

AHM-BT40-A10.180G 90 degree Aluminum Angle Head
BT40-ER20 90° Aluminum Angle Head (Female Thread Nut)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

 AHM ( BT-ER Type )

AHM-CAT30-A04.180G 90 degree Aluminum Angle Head

AHM-CAT30-A04.180G 90 degree Aluminum Angle Head
CAT30-ER25 90° Aluminum Angle Head
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-CAT30-A04.180G-I 90 degree Aluminum Angle Head

AHM-CAT30-A04.180G-I 90 degree Aluminum Angle Head
CAT30-ER25 90° Aluminum Angle Head (Internal Coolant)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-CAT30-A10.180G 90 degree Aluminum Angle Head

AHM-CAT30-A10.180G 90 degree Aluminum Angle Head
CAT30-ER20 90° Aluminum Angle Head (Female Thread Nut)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

 AHM ( BT-ER Type )

AHM-CAT40-A04.180G 90 degree Aluminum Angle Head

AHM-CAT40-A04.180G 90 degree Aluminum Angle Head
CAT40-ER25 90° Aluminum Angle Head
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation

- AHM ( BT-ER Type )

AHM-CAT40-A04.180G-I 90 degree Aluminum Angle Head

AHM-CAT40-A04.180G-I 90 degree Aluminum Angle Head
CAT40-ER25 90° Aluminum Angle Head (Internal Coolant)
Run-out：0.002 mm
Material：Aerospace Aluminum Alloy
R.P.M.：Max. 6000 RPM
Torque: Max. 15 Nm
Gear Ratio：1：1
Spindle Type: BT, SK(ISO), CAT
Standard Accessory：Open End Wrench, ER Wrench, ER Nut
Output Rotation: Reverse to Input Rotation


Angle Head Accessories
Collet

Collet

more
Extension

Extension

more
Flanged Setting Plate

Flanged Setting Plate

more
Setting Block / Stopper

Setting Block / Stopper





Angle Head Accessories

Setting Block / Stopper

Setting Block / Stopper
Setting Block for AHA-D, AHG, AHL, AHM Type Angle Head
It's customized item according to customer's Machine spindle dimension to fix Angle Head on the Machine Spindle.




Other Product In Group "HOLD WELL (9)"

ตัวแทนจำหน่าย HOLD WELL Angle Head
Aluminum Angle Head BT30
Air Dryer - HOLD WELL เครื่องทำลมแห้ง แอร์ดรายเออร์
ตัวแทน จำหน่าย oil skimmer
Roundness Measuring Machine
Angle Head BT40/BT50/HSK63/HSK100
New Product
Shaft Vise ปากกาจับงานกลม
Quick Change Tool Holder
View All
loading
