The Rotary Modules are distinguished by their precision, allowing the Driven Tool to attain a rotary capacity of 0.01mm.
Due to quality Gleason gears coupled with high-precision bearings, tools can arrive at a rotation speed of 6000 rpm.
Certified quality control.
Guaranteed for one year.

The toolholder catalog includes all type of attachments: HSK A – E, DIN 69871 and BT and are available for any job – Collet Chucks, Weldon, End Mill Holders, Boring Bars with double blades. Also available special toolholders on request.

OMAP TOOLS accessories are completed by Collets – ER DIN 6499, Flex and Ultraflex. Nuts for various collets: Standard ER 6499/E, ER hexagon, ER Mini or with external thread. Retention Knobs for BTMAS, ISO 7388-2A and DIN 69872.

The Angle Heads are manufactured for all types of NC Machines. Our concern for accuracy and precision, guarantees 0.01 mm rotation precision. Quality Gleason gears coupled with high-precision bearings allow for tool rotation at a speed of 10,000/15,000 G/min. Guaranteed for one year.

The catalog of Collet Chucks includes all types of attachments: HSK E – F and DIN 69871 ready for any type of application. End Mill Holders and Stub Harbors are also available. Dimensions available are ISO 25-30-40. Special request needs can also be studied.
